Oil and Gas Lubrication System Overview

The oil and gas lubrication system is mainly composed of an electric lubrication pump; an oil and gas mixer; a pneumatic processing component and a control component. The oil and gas lubrication system is a typical gas-liquid two-phase fluid. Suitable for high speed spindles or other oil and gas lubrication.

Performance and characteristics

1,The system is equipped with a solenoid valve and a pulse valve forprecise control of the air source(Input pressure: 4-8 bar), and the spray frequency can be directly adjusted through the pulse valve;

2,Oil and gas are output by concentric tubes and mixed at the nozzlefor high speed spraying. The volume of gas supply and oil supply canbe adjusted independently, effectively improving the efficiency ofspray cooling.

3,The system modular design, according to user requirements can befreely combined with the number of spray orifices.

4,Equipped with a low liquid level sensor, can realize the system oilmonitoring Innovative structural design of the product can realize theinfinitely adjustable displacement.

5,Adjustable range of 0.003mL/cy-0.03mL/cy, at the same time, there isan indicator lever when the pump is working, which can effectivelymonitor the operating status and ensure the reliable and safeoperation of the system.

6,The consumption of lubricant is very small, which can effectivelyreduce the environmental pollution, with the effect of environmentalprotection and working environment improvement.

7,Applicable medium: vegetable oil.
