1.Liquid level switch and pressure switch (optional) are provided. When oil volumeor pressure is insufficient, abnormal signal is output.
2.The panel indicator light indicates power and lubrication status of the oilinjection mold.
3.The system is provided with FEED key, and compulsory lubrication is applied.
4.The volumetric system is provided with decompression device, used with BFABFB/BFD/BFE/BFG/BFH distributor,Refer to page 03-10.
5.Overflow valve is provided to prevent damage by oil injector and pipeline.
6.Internal fuse is provided to prevent lC board and motor damaged by shortcircuit.
| item | Volumetric |
| Warranty | 1 years |
| Brand Name | BAOTN |
| Model Number | BTD |
| Place of Origin | China |
| Application | Automotive Industry, cnc lather |
| Power Source | Electric |
| Pressure | Low Pressure |
| Structure | Gear Pump |
| Outlet Size | 6mm |
| Voltage | 12V 24V 110V 220V |
| Power | 60W |
| Rated throughtout Pressure | 2Mpa |
| Maximum throught pressure | 3.5Mpa |
| Throughout | 200cc/min |
| Oil tank volume | 3/4/6/8L |
