GEO-2 Progressive grease lubrication pump oil tank pump

Short Description:

● Quantify lubrication of each lubrication point.

● Pressure, liquid level alarm has signal output.

● Various voltages can be customized.

● Pressure rises fast and stable, depressurization is stable.

Warranty Period: 2 Years

Min.Order Quantity: 1 Piece/Pieces

Supply Ability: 10000 Piece/Pieces per Month

Quantity:



Inquire Add to Basket

Performance and characteristics

1,The duty cycle of the lubrication pump can be controlled by the main PLC or a separate controller

2,Built-in solenoid valve pressure relief device,the system automatically releases pressure quickly when the lubrication pump stops running

3,Equipped with a pressure regulating valve device,the working pressure of the lubrication pump can be independently set to ensure safe operation

4,An exhaust valve arrangement is provided to eliminate lubrication of the air in the pump chamber and to ensure that lubrication pump drains the oil smoothly.

5,For low oil level transmitters,normally open or normally closed contacts can be selected depending on the system.

6.The lubrication system is equipped with a pressure swith,which can effectively monitor the pipeline system to interrupt the flow,leakage and other pressure shortages.

7,The use of canned grease can reduce impurities,mix in grease,and be easy to replace without polluting the environment

8,Equipped with a pressure relief device in the volumetric system
